Products Description:
Model FSZ self-priming stainless steel pump series parameters:
Capacity: 0.6-5.4 m3 / h
Head: 12-40 meters
Motor protection grade: IP55/IP54
Power: 0.37 KW to 0.9 KW
Working voltage: 220V or 380V
Liquid Temperature: -15 ℃ to +45 ℃
Environment Temperature: -15 ℃ to + 40 ℃
The motor speed: 2900 r/min
The maximum working pressure: 8 bar
Over loadprotector in three phase is available upon request
Material:
1. casing and back cover:304 stainless steel
2. impeller : 304 stainless steel or reinforced plastic
3. guide plate and ejector: reinforced plastic
Application:
1. transporting clean water and light corrosive liquid.
2. movement of water for deomesitc
3. industrial applications
4. car washing
5. car washing
6. gardening, small irragation
7. fountains
Product Picture:
Product Performance Date:
| FSZ self-priming stainless steel pump(220V&380V) | |||||||||||||||
| Model |
Power (KW) |
Input Caliber (mm) |
Output Caliber (mm) |
Capacity | L/min | 0 | 10 | 20 | 30 | 40 | 50 | 60 | 70 | 80 | 90 |
| m³/h | 0 | 0.6 | 1.2 | 1.8 | 2.4 | 3.0 | 3.6 | 4.2 | 4.8 | 5.4 | |||||
| FSZ-037 | 370W | 25 | 25 | Head | Meter | 35 | 28 | 23 | 18 | 15 | 12 | ||||
| FSZ-045 | 450W | 25 | 25 | Head | Meter | 38 | 32 | 26 | 22 | 17 | 14 | ||||
| FSZ-060 | 600W | 25 | 25 | Head | Meter | 41 | 35 | 29 | 24 | 20 | 16 | ||||
| FSZ-075 | 750W | 32 | 25 | Head | Meter | 41 | 36 | 33 | 29 | 28 | 25 | 22.5 | 21 | 19 | 17 |
| FSZ-090 | 900W | 32 | 25 | Head | Meter | 45 | 40 | 36 | 33 | 31 | 28 | 26 | 25 | 23 | 21 |
