Products Description:
FZD-DW frequency conversion booster pump equipment series parameters:
Material: the whole flowing components are 304 stainless steel
Capacity: 0.5-22m3 / h
Head: 11-53 meters
Motor protection grade: IP55/IP54
Power: 0.37 KW to 3 KW
Working voltage: 220V or 380V, the voltage can be customized
Liquid Temperature: -15 ℃ to + 80 ℃
Environment Temperature: -15 ℃ to + 40 ℃
The motor speed: 2900 r/min
Characteristic: steady pressure of water supply, current overload protection, lack of water protection,protection function of low water level
Application:
1. residential building, office building water supply in costant pressure
2. industrial producting and processing that need frequency conversion water booster
3. all kinds of occasion need costant pressure water supply and etc
FZD-DW frequency conversion booster pump Product Picture:
Product Performance Date:
| FZD-DW frequency conversion booster pump equipment(220V/380V) | ||||||||||||
|
Model |
Power |
InPut (mm) |
Output (mm) |
Capacity | L/min | 8.3 | 16.7 | 25 | 33.3 | 41.7 | 50 | 58.3 |
| m³/h | 0.5 | 1.0 | 1.5 | 2.0 | 2.5 | 3.0 | 3.5 | |||||
| FZD-DW2-20/037 | 370W | 25 | 25 | Head | meter | 18 | 17 | 16 | 15 | 14 | 13 | 11 |
| FZD-DW2-30/037 | 370W | 25 | 25 | Head | meter | 26 | 25 | 24 | 22.5 | 21 | 19 | 16 |
| FZD-DW2-40/055 | 550W | 25 | 25 | Head | meter | 35 | 32.5 | 31 | 29.5 | 27.5 | 25.5 | 21 |
| FZD-DW2-50/055 | 550W | 25 | 25 | Head | meter | 44 | 41 | 39 | 36.5 | 34 | 31 | 26 |
| FZD4-DW60/075 | 750W | 32 | 25 | Head | meter | 53 | 50 | 47 | 44 | 40 | 36 | 30 |
| FZD-DW frequency conversion booster pump equipment(220V/380V) | ||||||||||||
| Model | Power |
Input (mm) |
Output (mm) |
Capacity | L/min | 16.7 | 33.3 | 50 | 66.7 | 83.3 | 100 | 116.7 |
| m³/h | 1 | 2 | 3 | 4 | 5 | 6 | 7 | |||||
| FZD-DW4-20/055 | 550W | 32 | 25 | Head | meter | 18 | 17 | 16.5 | 15.5 | 14.5 | 13 | 11 |
| FZD-DW4-30/055 | 550W | 32 | 25 | Head | meter | 27 | 26 | 25 | 24 | 22.5 | 20 | 17.5 |
| FZD4-DW40/075 | 750W | 32 | 25 | Head | meter | 36 | 35 | 33.5 | 32 | 29.5 | 26.5 | 23 |
| FZD-DW frequency conversion booster pump equipment(220V/380V) | |||||||||||||
| Model | Power |
Input (mm) |
Output (mm) |
Capacity | L/min | 83.3 | 100 | 116.7 | 133.3 | 150 | 166.7 | 183.3 | 200 |
| m³/h | 5 | 6 | 7 | 8 | 9 | 10 | 11 | 12 | |||||
| FZD-DW8-20/075 | 750W | 40 | 40 | Head | meter | 20 | 19.5 | 18.5 | 18 | 17.5 | 16.5 | 15.5 | 14 |
| FZD-DW8-30/110 | 1100W | 40 | 40 | Head | meter | 29.5 | 29 | 28 | 27 | 26 | 24.5 | 23 | 21 |
| FZD-DW8-40/150 | 1500W | 40 | 40 | Head | meter | 39 | 38 | 37 | 36 | 35 | 33 | 31 | 29 |
