GDD inline pump type air condition pump CONTACT US:86-020-89230513
EMAIL:3105442310@qq.com |
Products Description:
Model GDD inline pump series parameters:
Type: air condition pump
Material: cast iron
The motor speed: 1450 r/min
Capacity: 3.5-1440m³ / h
Head: 10-71m meters
Power: 0.75 KW to 132 KW
Working voltage: 220V or 380V, and other voltages: like 110V,130V, 240V and etc
Liquid Temperature: -15 ℃ to +80 ℃
Environment Temperature: -15 ℃ to + 40 ℃
Over loadprotector in three phase is available upon request
Application:
1. transporting clean water
2. water boosting, water supply for high building
3. industrial applications
4. pumping hot and cold water for heating and cooling system
5. pressure boosting system
6. firefight system
7. liquid transfer in industry ,agriculture, horticulture
GDD inline pump type air condition pump Product Picture:
Product Performance Date:
GDD inline pump type series parameters
Model
Capacity(m³ /h)
Head(m)
Power(KW)
Speed(r/min)
GDD32-5
6.3
5
0.55
1450
GDD32-8
6.3
8
0.55
1450
GDD32-12.5
3.75
6.3
7.5
13
12.5
11
0.75
1450
GDD32-20
3.75
6.3
7.5
21
20
19
1.5
1450
GDD32-20A
3.5
5.9
7.0
18
17
16
1.1
1450
GDD40-5
12.5
5
0.55
1450
GDD40-8
12.5
8
0.75
1450
GDD40-12.5
7.5
12.5
15
13.2
12.5
11.5
1.1
1450
GDD40-12.5A
7
11.7
14
11.5
11
10
0.75
1450
GDD40-20
7.5
12.5
15
21
20
19
2.2
1450
GDD40-20A
7
11.7
14
18
17.5
16.5
1.5
1450
GDD40-30
7.2
12
14
32
30
28
3
1450
GDD40-30A
6.5
11
13
24.5
24
22
2.2
1450
GDD50-8
10.8
18
21.6
9.5
8
7
1.1
1450
GDD50-8A
9.5
16
18
8
7
6
0.75
1450
GDD50-12.5
10.8
18
21.6
13.2
12.5
11
1.5
1450
GDD50-12.5A
9.5
16
18
11.6
10.5
10
1.1
1450
GDD50-17
10.8
18
21.6
19
17
14
2.2
1450
GDD50-20
10.8
18
21.6
23
21
18
3
1450
GDD50-30
10.8
18
21.6
33
30
25
4
1450
GDD50-30A
9.5
17
20.5
29
26
21.5
3
1450
GDD65-8
15
25
30
9
8
7.2
1.5
1450
GDD65-12
15
25
30
13.2
12.5
11.5
2.2
1450
GDD65-12A
14
23.4
28
11.5
11
10
1.5
1450
GDD65-20
15
25
30
21
20
18.8
3
1450
GDD65-20A
14
23.4
28
18.4
17.5
16.4
2.2
1450
GDD65-32
15
25
30
33
32
31
5.5
1450
GDD65-32A
14.3
23.8
28.5
29.5
28.5
26
5.5
1450
GDD65-32B
13.6
22.7
27.2
27
25
23
4
1450
GDD80-8
50
8
2.2
1450
GDD80-12
30
50
60
13.3
12.5
11.8
4
1450
GDD80-12A
28
46.8
56
11.9
11
10
3
1450
| GDD inline pump type series parameters | ||||
| Model | Capacity(m³ /h) | Head(m) | Power(KW) | Speed(r/min) |
| GDD80-20 |
30 50 60 |
23 20 15 |
5.5 | 1450 |
| GDD80-20A |
32 46 56 |
20 17 15 |
4 | 1450 |
| GDD80-20B |
25.6 42.8 51.1 |
15.5 14.5 13.5 |
3 | 1450 |
| GDD80-32 |
30 50 60 |
34 32 30 |
11 | 1450 |
| GDD80-32A |
28.7 47.7 57.5 |
31 28.5 27 |
7.5 | 1450 |
| GDD80-32B |
25.7 42.9 51.6 |
25 23.5 22 |
5.5 | 1450 |
| GDD100-12 |
60 100 120 |
14.5 12.5 11 |
5.5 | 1450 |
| GDD100-12A |
56 93.5 112 |
12.8 11 9.7 |
4 | 1450 |
| GDD100-12B |
52 88 105 |
11 9.5 8.3 |
4 | 1450 |
| GDD100-15 |
81.2 125 134 |
17.5 15.5 14.8 |
7.5 | 1450 |
| GDD100-19 |
60 90 120 |
21 19 15 |
7.5 | 1450 |
| GDD100-19A |
50 80 110 |
17 15 11.5 |
5.5 | 1450 |
| GDD100-21 |
39 60 75 |
24 21 16 |
5.5 | 1450 |
| GDD100-23 |
60 122 144 |
25 23 20 |
15 | 1480 |
| GDD100-34 |
60 100 120 |
36 34 31 |
18.5 | 1480 |
| GDD100-32 |
60 90 120 |
34 32 29 |
15 | 1480 |
| GDD100-32A |
60 90 115 |
31 28 25.5 |
11 | 1480 |
| GDD100-32B |
48 76 100 |
27 24 20 |
7.5 | 1480 |
| GDD100-50 |
60 100 120 |
52 50 47 |
30 | 1480 |
| GDD100-50A |
56 93.6 112 |
46 44 41 |
22 | 1480 |
| GDD100-50B |
54.6 90 108 |
40 38 35 |
18.5 | 1480 |
| GDD100-50C |
53 75.5 90.5 |
36 34 31.5 |
15 | 1480 |
| GDD125-22 |
95 148 180 |
24.5 22 20 |
15 | 1480 |
| GDD125-20 |
110 160 200 |
23 20 17 |
15 | 1480 |
| GDD125-20A |
104 150 190 |
20 17 15 |
11 | 1480 |
| GDD125-34 |
90 148 172.8 |
36.5 34 30 |
22 | 1480 |
| GDD125-32 |
110 160 200 |
36 32 28 |
22 | 1480 |
| GDD125-32A |
100 150 190 |
32 28 23 |
18.5 | 1480 |
| GDD125-32B |
90 140.4 180 |
29 25 20 |
15 | 1480 |
| GDD125-50 |
110 160 200 |
55 50 45 |
37 | 1480 |
| GDD inline pump type series parameters | ||||
| Model | Capacity(m³ /h) | Head(m) | Power(KW) | Speed(r/min) |
| GDD125-50A |
100 150 190 |
49 45 40 |
30 | 1480 |
| GDD125-50B |
90 140 168 |
43 37 33 |
22 | 1480 |
|
GDD150-22 |
144 225 288 |
23.5 22 18.5 |
22 | 1480 |
| GDD150-20 |
120 200 240 |
22.5 20 17.5 |
18.5 | 1480 |
| GDD150-20A |
112 187 224 |
19.5 17 15 |
15 | 1480 |
| GDD150-20B |
108 180 216 |
18 15 13 |
11 | 1480 |
| GDD150-32G |
144 240 288 |
34 32 28 |
30 | 1480 |
| GDD150-32 |
129 216 259.2 |
34 32 29 |
30 | 1480 |
| GDD150-32A |
112 187 224 |
30 28 25 |
22 | 1480 |
| GDD150-32B |
104 173 208 |
25.5 24 21.8 |
18.5 | 1480 |
| GDD150-49 |
144 245 300 |
55 49 44 |
55 | 1480 |
| GDD150-49A |
144 245 300 |
52 45 38 |
45 | 1480 |
| GDD150-50 |
120 200 240 |
53 50 46 |
45 | 1480 |
| GDD150-50A |
112 187 225 |
47 44 40 |
37 | 1480 |
| GDD150-50B |
104.6 173 209 |
40 38 35 |
30 | 1480 |
| GDD200-24 |
200 300 360 |
26 24 21 |
30 | 1480 |
| GDD200-24A |
198 280 340 |
20 18 15 |
22 | 1480 |
| GDD200-24B |
168 250 300 |
17 15 13 |
18.5 | 1480 |
|
GDD200-32 |
200 300 360 |
33 32 30 |
37 | 1480 |
| GDD200-32A |
198 280 340 |
29 28 24 |
30 | 1480 |
| GDD200-32B |
200 300 360 |
26 24 21 |
30 | 1480 |
| GDD200-48 |
200 300 360 |
51 48 43 |
55 | 1480 |
| GDD200-48A |
198 280 340 |
45 42 37 |
45 | 1480 |
| GDD200-48B |
240 400 460 |
40 37 32 |
37 | 1480 |
| GDD250-20 |
225 374.4 431 |
22.6 20 17 |
30 | 1480 |
| GDD250-20A |
445 630 758 |
18.5 16 14 |
22 | 1480 |
| GDD250-32 |
240 400 480 |
37 32 28.5 |
55 | 1480 |
| GDD250-32A |
226 374 432 |
33 28 25 |
45 | 1480 |
| GDD250-32B |
210 350 403 |
27.5 24 21.2 |
37 | 1480 |
| GDD250-38 |
445 630 758 |
42 38 32 |
90 | 1480 |
| GDD inline pump type series parameters | ||||
| Model | Capacity(m³ /h) | Head(m) | Power(KW) | Speed(r/min) |
| GDD250-38A |
360 600 720 |
39 32 26 |
75 | 1480 |
| GDD250-50 |
240 400 460 |
55 50 45 |
90 | 1480 |
| GDD250-50A |
228 380 437 |
49 44.5 40 |
75 | 1480 |
| GDD250-50B |
210 340 401 |
42 38 34 |
55 | 1480 |
| GDD300-15 |
360 500 612 |
18.5 15 12 |
30 | 1480 |
| GDD300-15A |
324 468 576 |
16.5 12.5 10 |
22 | 1480 |
| GDD300-22 |
518 792 940 |
25 22 18.5 |
75 | 1480 |
| GDD300-17 |
450 750 900 |
20 17 14 |
55 | 1480 |
| GDD300-17A |
375 625 750 |
20 17 15 |
45 | 1480 |
| GDD300-24 |
360 500 612 |
27 24 17 |
45 | 1480 |
| GDD300-24A |
300 500 600 |
22 20 17 |
37 | 1480 |
| GDD300-25 |
612 800 915 |
27 25 20 |
75 | 1480 |
| GDD300-25A |
560 750 850 |
23 20 17 |
55 | 1480 |
| GDD300-25G |
700 900 1100 |
27 25 20 |
90 | 1480 |
| GDD300-25GA |
700 900 1100 |
22 20 17 |
75 | 1480 |
| GDD300-32 |
450 750 900 |
35 32 28 |
90 | 1480 |
|
GDD300-32A |
551 720 850 |
31 26 23 |
75 | 1480 |
| GDD300-38F |
612 800 915 |
42.5 38 32.5 |
110 | 1480 |
| GDD300-38FA |
540 765 850 |
36 32 28 |
90 | 1480 |
| GDD300-38G |
700 900 1100 |
42 38 33 |
132 | 1480 |
| GDD300-38GA |
700 900 1100 |
37 32 26 |
110 | 1480 |
| GDD300-40 |
360 500 612 |
43.5 40 33.5 |
75 | 1480 |
| GDD300-40A |
324 468 576 |
36.5 31.5 26 |
55 | 1480 |
| GDD300-50 |
445 630 758 |
53 50 46 |
132 | 1480 |
| GDD300-50A |
420 600 725 |
45 42 38 |
110 | 1480 |
| GDD300-65 |
360 500 612 |
71 65 56 |
132 | 1480 |
| GDD300-65A |
324 468 576 |
61 54 50 |
110 | 1480 |
| GDD350-17 |
750 1250 1500 |
21 17 12 |
90 | 1480 |
| GDD350-17A |
600 1000 1200 |
21 17 14 |
75 | 1480 |
| GDD350-20 |
612 800 935 |
23 20 16 |
55 | 1480 |
| GDD inline pump type series parameters | ||||
| Model | Capacity(m³ /h) | Head(m) | Power(KW) | Speed(r/min) |
| GDD350-20A |
504 720 829 |
20 17 14 |
45 | 1480 |
| GDD350-26 |
972 1260 1440 |
32 26 22 |
110 | 1480 |
|
GDD350-26A |
864 1116 1296 |
26 21.5 16 |
90 | 1480 |
| GDD350-32 |
900 1200 1400 |
35 32 26 |
160 | 1480 |
| GDD350-32A |
819 1092 1310 |
31 28 23 |
132 | 1480 |
| GDD350-32B |
745 1000 1200 |
27 25 20 |
110 | 1480 |
| GDD350-44 |
972 1260 1476 |
50 44 37 |
200 | 1480 |
| GDD350-44A |
864 1200 1332 |
41 36 30 |
160 | 1480 |
| GDD350-44B |
900 1200 1300 |
35 30 28 |
132 | 1480 |
| GDD400-12.5 |
1200 1600 1900 |
14 12.5 10.5 |
75 | 1480 |
| GDD400-12.5A |
1092 1456 1720 |
12 10.5 9 |
55 | 1480 |
| GDD400-20 |
1200 1600 1900 |
23 20 15 |
110 | 1480 |
| GDD400-20A |
1092 1456 1720 |
19.5 17 13 |
90 | 1480 |
| GDD400-32 |
1200 1600 1900 |
35 32 26 |
200 | 1480 |
| GDD400-32A |
1092 1456 1720 |
30 27.5 22.5 |
160 | 1480 |
| GDD400-32B |
994 1325 1573 |
26 23.5 19 |
132 | 1480 |
| GDD500-13 |
1620 2020 2340 |
15 13 10.4 |
110 | 1480 |
| GDD500-22 |
1620 2020 2340 |
24.5 22 19.4 |
160 | 1480 |
| GDD500-22A |
1400 1746 2020 |
20 17 15 |
132 | 1480 |
| GDD500-27 |
1620 2020 2340 |
31 27 21 |
200 | 1480 |
